5mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module

5mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module

  • Highlight

    5mp Raspberry PI Camera Module

    ,

    Raspberry PI Camera Module ESP32

    ,

    OV5640 Mipi Camera Module

  • Sensor
    OV5640
  • Focusing Range
    10cm To Infinity
  • Focal Length
    3.37mm
  • F Number
    2.8
  • Fov(D)
    67°
  • TV Distortion
    <1.0%
  • Software Support
    ESP32, Raspberry Pi
  • Focus Type
    Auto Focus
  • Image Sensor
    CMOS
  • Interface
    MIPI
  • Place of Origin
    Guangdong , China
  • Brand Name
    SINCEREFIRST
  • Certification
    CE, FCC, RoHS, REACH, ISO
  • Model Number
    SF-AOV5640-MIPI-AF-70L
  • Minimum Order Quantity
    5 pcs
  • Price
    Negotiable
  • Packaging Details
    Package, Carton Box
  • Delivery Time
    7 - 15 Work Days
  • Payment Terms
    L/C, Western Union, T/T, MoneyGram, Paypal and Others
  • Supply Ability
    350000 pcs / month

5mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module

5mp FPC Auto Focus Raspberry Pi OV5640 MIPI Camera Sensor Module​

5mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module 0
Specificaitons


Model No. SF-AOV5640-MIPI-AF-70L
Sensor OV5640
Pixel 5MP
Focus Type Auto Focus
Interface MIPI CSI Interface
View Angle 67°
Output Format YUV422
Obeject Distance 10cm to Infinity
Compliance FCC, RoHS
Warranty 10 Years



Description

The OV5640 MIPI camera module is a low-power, high-performance camera module that features a 5-megapixel OmniVision CMOS sensor. It is designed to be integrated into a wide range of applications, including mobile phones, tablets, and other portable devices.
The camera module supports a wide range of output interfaces, including MIPI-CSI, LVDS, and parallel. This makes it easy to integrate into a wide range of systems. It also supports a variety of image formats, including JPEG, BMP, PNG, and RAW.
The OV5640 MIPI camera module features a range of advanced features that help to ensure high image quality. These include advanced image processing algorithms, automatic white balance, and automatic color correction. It also features a range of exposure control options, including automatic, manual, and program modes.


Features

◆Omnivision OV5640 Image Sensor with pixel size of 1.4µm
◆Auto Focus, Auto Exposure and Auto White Balance support
◆Normal Flip, Mirror and Rotate support
◆Image Area: 3673.6 µm x 2738.4 µm
◆Focus Distance: 10cm to Infinity
◆MIPI-CSI, Auto-focus OV5640 camera sensor module
◆Compact size
◆YUV video format



Advantage

In addition to its advanced features, the OV5640 MIPI camera module is also very compact and lightweight. This makes it ideal for integration into portable devices where space and weight are at a premium.
Overall, the OV5640 MIPI camera module is an excellent choice for those looking to add high-quality camera functionality to their portable devices.





Customized Service

We can customize FPC length, module shape, module head size, lens holder, imaging direction, pinout, connector, VCM, lens, firmware, etc.



5mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module 1





Why Choose US?


5mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module 2





Applicaitons

Medical Devices, Tablets, Biometrics(Iris Scan) ,Low Vision, Electronic Microscope, Surveillance, Ocr Readers, Document Scanners, Inspection Cameras, Lab Equipment etc...



5mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module 3




Customized Process

1. You can provide drawings or samples, as well as request documentation and developed by
our engineering staff.

2. Communication or Meeting
3. We will communicate with you in detail to determine somewhat product you need and try to set the most suitable product for you
according to your needs.

4. Sample Development
5. Determine the details of the development sample and the delivery time. Communicate at any time to ensure smooth progress.
6. Sample Testing
7. Test and age on your application, feedback test results, no need to modify, mass production.





About us

5mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module 4





Cooperative Brands & Customers



5mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module 5





Details Pictures


5mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module 65mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module 75mp Raspberry PI Camera Module ESP32 OV5640 Mipi Camera Module 8
